Motor Lamination Stamping Machine

Capacity: 60 tons, 80 tons, 125 tons.
Series: APH series
Etone / TYD is professional on the high speed presses, motor lamination stamping machine, high speed punch presses, high speed lamination press for motor parts and stator and rotor. Our press machines are exported to Turkey, Iran, India, Indonesia, Thailand, Vietnam, Brazil, USA and some Europe and America countries. Many customers buy the motor lamination stamping machine from us, because of our good quality. Our machine can reach to Japan Super precision.

Send Inquiry

Product Description

Motor Lamination Stamping Machine

We regularly perform our spirit of ''Innovation bringing progress, Highly-quality making certain subsistence, Administration marketing benefit, Credit score attracting customers for Online Exporter China High Speed Lamination Press Good Quality High Speed Press Machine, We welcome new and outdated prospects from all walks of lifetime to get in touch with us for foreseeable future small business interactions and mutual achievement! Online Exporter China Press Machine, Stamping Machine, Excellent quality, competitive price, punctual delivery and dependable service can be guaranteed. For further inquires please do not hesitate to contact us. Thank you - Your support continuously inspires us.

1.Product Description

Etone is professional on the high speed presses,motor lamination stamping machine, high speed punch presses, high speed lamination press for motor parts and stator and rotor. Now, we become the  best high speed press machine factory and supplier in China. Our company's high speed press machine and high speed lamination press are energy-saving, safe, precise, and efficient, and have exported to more than 30 countries all over the word.


2.Applicable area

motor lamination stamping machines are suitable for high-speed and precision automatic stamping of automatic riveting iron cores such as new energy automobile motors, compressor motors, and energy-efficient industrial motors.


3.Motor lamination stamping machine Product Features

Four - columned top cylinder structure

Double-drive technology

Slider multi-point force

High-rigidity cast pre-stress machine body

Multiple aging treatment



 Low inertia clutch brake

Insert bearing

Constant temperature lubricated cooling system

Straight column + octagonal precision guide



 High rigidity

High strength casting bed, stiffness 1 / 15000-1 / 20000



 High precision

Static precision: 1/ 2 ofJIS level

Lower dead point dynamic accuracy: JIS superprecision level



 Motor lamination stamping machine Complete specification

From 60 tons to500 tons full series, a variety of working table, to meet the needs of higher efficiency motor materials thinner, higher accuracy, faster speed of high speed precision stamping requirements.


4.Motor lamination stamping machine Product Parameter:




APH-125

APH-80

APH-60

Tonnage

ton

125

80

60

Travel

mm

30

25

20

30

25

20

30

25

20

Number of strokes per minute

s.p.m

200---900

200-1000

200-1200

200-800

200-900

200刁100

200--800

200-900

200-1000

Lower table size

mm

600x450

750x550

950x650

Blanking hole

mm

400x100

550x125

700x125

Sliding block area

mm

600x320

750x380

950x420

Die height adjustment stroke

mm

225-275

240-290

300-350

Die height adjustment motor

kw

0.4

0.4

0.4

Feeding line height

mm

120

135

160

Main motor

kw

11

15

19


5.Machine Standard accessories

1Lubrication system: apply high pressure oil from crankshaft center(Japan SHOWA)

2 PLC control system: provide cutting signals

3 Bearing: NSK Japan

4 Oil atomizer: SMC Japan

5 Air switch and contactor: Schnede France

6 Oil seal: NOK Japan

7 Auto-balancing system design

8 Electronic slide adjustment system

9 T-Mobile operating table

10 Hydraulic Slide Locking Device

11 Material Ending Detector

12 Inverter:

13 Electric Clutch valve

14 Clutch structure: (OMPI Itlay )

15 Relay: Omron

16 Angle and speed showing: TOYO

17 Air pressure joint: ARK Korea

18 Crankshaft: SNCM8,GrindingGuid: AKS Jpan

19 Auto-Thermal Balancing in ram/Slider micro inching position

20 Miss-Feed detector

21 Tool box with machine shipping 1


6.Standard accessories:

1 High Speed Gear Feeder

2 Double rack Uncoiler

3 Straightener with S loop

4 Automatic oil device to die

5 Auto Power Die lifer system:

6 Die Arm system:2 pcs

7 Anti-vibration system

8 Chute controller:

9 Die solenoid valve installation system: 10 pcs



7.Optional Accessories

1. Bottom dead detector

2. Quick die clamping device

3. Safety door

4. Others
